Gobo Colour 2

Glass gobo with two colour filters. The graphic is lasered out of the chrome and the two colour filters. We will check your graphic file and you will receive a non-binding offer from us. For graphics with poor quality, we offer digital image editing, which may incur additional costs.

SKU: 06330800

File formats

File formats for your projection motif

Vector files

Vector data describe simple to complex graphics with mathematical formulas that define the origin, direction, size, colour etc. of an area or line. The main advantage of a vector file is that the graphics can be resized without loss of quality.

File formats: Best suited for:
  • Adobe Illustrator (.ai)
  • Corel Draw (.cdr)
  • Encapsulated Postscript (.eps)
  • Black & White
  • Black & Colour
  • Colour 1
  • Colour 2
  • Colour 3

Pixel files

Pixel data are best suited to reproduce photographic images. All digital cameras and scanners generate pixel data. Pixel data cannot be enlarged without loss of quality. Large files are often required for detailed and sharp photographic images.

File formats: Best suited for:
  • JPEG (.jpg, “high” or “maximum” quality)
  • TIFF (.tif, optional compression)
  • Adobe Photoshop (.psd)
  • Greyscale
  • Multicolour

To avoid difficulties in the representation of fonts, characters in vector files should be completely converted into paths (line art). Please rasterize Photoshop layers with text before submitting. If you are unsure about the right file format, we will be happy to advise you. The rules listed below serve as a simplified orientation.

Colour filters

The right colours for your projection motif

Dichroic colour filters are characterised by the highest colour purity and brilliance. A range of 13 standard filters is available to give your motif the desired colours. Special colours that fit in uncompromisingly with your corporate design can be created either by colour mixing or, for larger quantities, by using colour filters manufactured to customer specifications.

yellow warm yellow orange
Yellow, ca. Pantone Process Yellow Warm Yellow, ca. Pantone 137 Orange, ca. Pantone 151
04 warm red pink warm pink
Warm Red, ca. Pantone 485 Pink, ca. Pantone 225 Warm Pink, ca. Pantone 237
magenta violet medium blue
Magenta, ca. Pantone Process Magenta Violet, ca. Pantone 254 Medium Blue, ca. Pantone 300
bright blue turquoise cold green
Bright Blue, ca. Pantone Process Cyan Turquoise, ca. Pantone 321 Cold Green, ca. Pantone 3288
warm green
Warm Green, ca. Pantone 368

All colour specifications refer to a projection with a lamp adjusted to 6500° kelvin on a neutral white projection surface. Please note that each screen displays colours differently. Colour deviations in this representation are for technical reasons and cannot be avoided.

Sizes

Projection motifs of all sizes

Derksen produces glass gobos from 22.5 to 105 mm diameter, for any type of projection system on the market.

Gobo Size - Image Size

  • The gobo size is equivalent to the outer diameter of the gobo.
  • The image size indicates the maximum image area that the projector can display.

Due to the large number of projection systems and the constant technical changes made by equipment manufacturers, it is not possible for us to archive reliable data on gobo and image size. Therefore, please state the current dimensions of your gobo with every enquiry. This information can be found in the manufacturer’s data sheets or in the operating instructions supplied.
