PHOS 65 downlight compact
Compact LED projector with great effect
- Output power: 60W
- Luminous flux of the projector: 3,910 lumens
- Projection lens: 85 mm Standard
- LED service life (L70): 35,000 hours
- Cooling: active – 27 dBA
- Dimensions (W x H x D): 150 x 257 x 150 mm
5.9″ x 10.1″ x 5.9″ - NEW! Expected to be available from August 2023
 |  |  |  |
 |  |  |  |
 |  |
Description
PHOS 65 downlight compact is a particularly small projector that can be installed almost invisibly in a false ceiling with a built-in diameter of only 130 mm. Setting up and focusing the projection is particularly quick thanks to the new magnetic mount and the rotating focus. PHOS 65 downlight compact is equipped with the latest LED technology and is cooled with a fan. The LED driver is supplied with the projector and is placed in the false ceiling. The projection motif (gobo) can be changed without tools.
| PHOS downlight | PHOS downlight compact | |
|---|---|---|
 | |
|
| adjustable inclination: | -15° – +15° | not available |
| compatible lenses: | wide angle 45 mm wide angle 63 mm standard 85 mm telephoto 135 mm | standard 85 mm |
| deflecting mirror for projection onto walls: | optionally available | not available |
| installation diameter: | Ø 224 mm | Ø 130 mm |
| ceiling opening: | large, exposed | small, closed |
| projector head: | appears from the opening | is integrated in the ceiling |
| focusing: | shifting the lens | rotating the lens, with one hand |
Image Size & Brightness
<h2>Projection calculator PHOS 65 downlight compact</h2>
<p>
Please note: The results shown are approximate values. In reality the results may differ slightly. The calculation applies under the following conditions:</p>
<ul>
<li>The projection motif is circular and fills the image area of the gobo. Other shapes and objects, e.g. rectangles or fonts, are fitted into this maximum projection area.</li>
<li>The projection is at right angles to the projection surface.</li>
<li>The projection surface is a plane.</li>
</ul>
<p><a href=”https://www.derksen.de/wp-content/uploads/2020/04/gobo-image-2.png”><img class=”alignnone size-medium wp-image-2024″ src=”https://www.derksen.de/wp-content/uploads/2020/04/gobo-image-2-300×136.png” alt=”” width=”300″ height=”136″></a></p>
